We promote the use of lifepo4 lithium batteries in households to help families in globally.
Model: HM15
Massive Capacity: 51.2V 304Ah (15.56kWh) Energy Storage
High Power Output: Supports 200A continuous discharge current
Premium Cells: Built with high-density 304Ah LiFePO4 Prismatic cells (16S1P)
Smart Communication: Interfaces via RS485, CAN, and RS232
Robust Enclosure: IP55 rated metal casing (Floor-standing/Tower design)
Application: Ideal for high-demand residential backup, off-grid systems, and commercial storage
The HM15 is a heavy-duty energy storage solution designed for users requiring maximum power and capacity. With a nominal capacity of 304Ah, this single unit delivers a massive 15.5kWh of usable energy, making it one of the most energy-dense options in its class. It is engineered to power larger homes or small commercial setups, reducing the need to stack multiple smaller batteries.
Housed in a durable IP55 metal enclosure, the HM15 utilizes a 16S1P configuration with advanced 304Ah prismatic cells. This design allows for a high continuous discharge rate of 200A, ensuring it can handle heavy inductive loads (like air conditioners or pumps) without tripping. The integrated Smart BMS provides comprehensive protection and communicates seamlessly with inverters via CAN/RS485, ensuring your system runs safely and efficiently.
|
Feature
|
Specification
|
|---|---|
|
Model
|
HM15
|
|
Nominal Voltage
|
51.2V
|
|
Nominal Capacity
|
304Ah
|
|
Total Energy
|
15.56 kWh (15565Wh)
|
|
Operating Voltage
|
40V - 58.4V
|
|
Charge Voltage
|
58.4V ±2V
|
|
Max Charge Current
|
140A (Recommended ≤100A)
|
|
Max Discharge Current
|
200A
|
|
210A (1s delay)
|
200A
|
|
Internal Resistance
|
≤50mΩ @1kHz AC
|
|
Configuration
|
16S1P (304Ah Cells)
|
|
Mechanical & Environmental
|
|
|
Dimensions (L x W x H)
|
550 ±10mm × 300 ±10mm × 850 ±10mm
|
|
Weight
|
Approx. 125kg
|
|
Installation Type
|
Floor-Standing / Tower
|
|
Enclosure Rating
|
IP55
|
|
Charge Temperature
|
0°C ～ 55°C
|
|
Discharge Temperature
|
-20°C ～ 55°C
|
|
Storage Temperature
|
-10°C ～ 45°C (Recommended 15~35°C)
|
